Japanese quality
Production of high-quality coils
for long engine operation
for long engine operation
We operate from Chile
coils manufacturing
and insulation materials
ABOUT US
Our company
COMPANY
Our company has many years of experience in producing electric machine coils.
We have transferred our technical production process to an automated line, which gives our customers quality products and high work speeds. All this makes it possible to repair electric motors and manufacture new ones in a faster and more productive way.
Our products are solutions to your business tasks
Products
RBC grupo manufactures all types of coil sections and stator winding bars for electrical motors and AC/DC generators: traction, concentric and rotor. We provide services for all types of electrical motors, even those that have been discontinued. Due to the exact geometry of our products, installation takes 1 to 2 days. High quality of materials is essential for us, therefore we use only copper grades of the highest purity of 99.99%, as well as insulation of heat resistance classes F, H, C from the best manufacturers. of the world.
PERFECT GEOMETRY
simplicity, speed and quality of coils installation
ULTRA-RELIABLE INSULATION SYSTEM AND 100% QUALITY CONTROL AT ALL STAGES
ensuring the smooth operation of your engine
COPPER WIRE OF BRAND M0 AND M00
(purity 99.9999) – reducing losses, increasing the efficiency of the electric machine
FULL AUTOMATION OF THE COIL MANUFACTURING PROCESS
is a guarantee of the fulfillment of your order qualitatively and within the specified time, 0.001% of defects in 15 years.
PRODUCTION OF COILS OF ANY CLASS OF HEAT RESISTANCE:
to solve any of your tasks
DELIVERY FROM 14 DAYS WORLDWIDE
implementation of your projects of any urgency
Resin Rich System (including coils up to 18 kV)
The Resin Rich insulation system is compatible with motors and generators up to 18 kV. It is designed to resist severe environmental conditions due to its outstanding mechanical, thermal and electrical properties.
Insulation System for Low-Voltage Coils (up to 1 kV)
This system is designed for motors and generators with operational voltages up to 1 kV. It is used in case when no insulation tape can be used in order to ensure the insulation strength of coils.
VPI (up to 10 kV)
The Vacuum Pressure Impregnation (VPI) system has excellent mechanical and dielectrical properties.
The Resin Rich insulation system is compatible with motors and generators up to 18 kV. It is designed to resist severe environmental conditions due to its outstanding mechanical, thermal and electrical properties.
Insulation System for Low-Voltage Coils (up to 1 kV)
This system is designed for motors and generators with operational voltages up to 1 kV. It is used in case when no insulation tape can be used in order to ensure the insulation strength of coils.
VPI (up to 10 kV)
The Vacuum Pressure Impregnation (VPI) system has excellent mechanical and dielectrical properties.
COILS FOR AC ELECTRIC MOTORS AND GENERATORS
PARAMETERS OF AC SECTIONS
INSULATION F, H, C CLASSES HEAT RESISTANCE AND ABOVE
VOLTAGE UP TO 18 000 V
- Length of coils: 350–3500 mm.
- Slot angle: 0–180.
- Straight length: 230–2000 mm.
- Cross-section part: 5×12–30×60 mm.
INSULATION F, H, C CLASSES HEAT RESISTANCE AND ABOVE
- From soaked belts (hot pressing technology).
- From dry tapes based on mica paper or polyimide films (vacuum-
- injection soaking technology).
- Hybrid VPI/Resin Rich technologies.
VOLTAGE UP TO 18 000 V
ARMATURE COILS
PARAMETERS
ADDITIONAL INFORMATION
INSULATION F, H, C CLASSES HEAT RESISTANCE AND ABOVE
- Coil lengths up to 1500 mm (up to 2000 mm on agreement)
- Design: loop, wave and complex wave.
ADDITIONAL INFORMATION
- Flattening of the ends.
- Wire: Any wire (including polyimide-insulated wire)
- Testing: Electrical test for absence of inter-turn short circuits,
- tests of case insulation.
- Control of geometrical dimensions.
INSULATION F, H, C CLASSES HEAT RESISTANCE AND ABOVE
- From soaked belts (hot pressing technology).
- From dry tapes based on mica paper or polyimide films
- (vacuum-injection soaking technology).
- Hybrid VPI/Resin Rich technologies.
RODS FOR AC ELECTRIC MOTORS AND GENERATORS
ROD WINDING PARAMETERS
INSULATION F, H, C CLASSES HEAT RESISTANCE AND ABOVE
VOLTAGE UP TO 18 000 V
THE MOST COMMON GENERATORS:
- Maximum overall length - 5000 mm.
- The maximum length of the straight part is 2500 mm.
- Cross-section 40x100 mm.
- It is possible to perform transposition in the cross-section.
INSULATION F, H, C CLASSES HEAT RESISTANCE AND ABOVE
- From soaked belts (hot pressing technology).
- From dry tapes based on mica paper or polyimide films
- (vacuum-injection impregnation technology).
- Hybrid VPI/Resin Rich technologies.
VOLTAGE UP TO 18 000 V
THE MOST COMMON GENERATORS:
- T-series (TC) turbogenerators from 2.5 to 63 MW
WINDING KIT
Each kit includes installation materials to facilitate the replacement of damaged elements. Complete or reduced winding kits are available depending a customer's requirements. Materials within the kit can be made for heating classes F, H, C for VPI and Resin Rich insulation systems.
The complete set includes:
The reduced kit consists of:
The complete set includes:
- hollow cords;
- solder;
- copper wire;
- a set of fillers or material to make them;
- insulating materials by Elinar;
- wedges
The reduced kit consists of:
- a set of fillers or a plate of paronite
- insulating materials;
- wedges
DC MOTOR COMMUTATOR
- Diameters from 500 mm to 2000 mm
- Manifold types: collapsible/uncollapsible, coupling
- bolted/clamped with nut, glass band.
- Cocks: soft and rigid
APPLICATION FIELD
- Designed for operation in DC electric machines (electric motors and generators).
- Before release the collectors are subjected to technical control of electrical insulation resistance.
WE WILL DRAW UP AND MANUFACTURE YOUR ORDER QUICKLY AND WITH HIGH QUALITY:
- to your individual drawings
- for imported electric motors collectors using standard pressure cones and bushings
- fabrication of collectors on the provided sample
ANCHORS, ROTORS AND ACCESSORIES
- Weights up to 6 t.
- Length up to 2000 mm.
- Diameter up to 1500 mm.
DIELECTRIC COMPONENTS
- Material: STEF as well as ferromagnetic composite material.
- Thickness up to 50 mm.
- Length/width: 3000 x 1500 mm.
WEDGES AND SPACERS
- Material: STEF as well as ferrimagnetic composite material.
- Length/width/thickness of spacers: 1500 mm x 100 mm x 7 mm.
- Length/width/thickness of gussets: 200 mm x 37 mm x 8 mm.
- Chamfering: on customer request.
TURBINE GENERATOR ACCESSORIES
- Current carrying, insulating parts Contact rings.
- Power accumulators.
- Shims and insulating tubes.
rbc@rbcgrupo.cl
Contacts
The main task of RBC GRUPO is to help customers to solve any technical problem related to the winding of electrical machines. For this purpose we have assembled a team of leading experts, provided the company with high-tech equipment and reliable partners.
ADVANTAGES
PERFECT GEOMETRY
01
SUPER RELIABLE INSULATION SYSTEM AND 100% QUALITY CONTROL AT ALL STAGES
ensuring smooth engine operation
02
WIRE COPPER CLASSIFICATION M0 and M00
preserving and improving the energy efficiency of your electrical machines
03
conducting projects of any urgency
04
SUPPORT OF OUR TECHNICAL DEPARTMENT
support and confidence at all stages of cooperation
05
PRODUCTION OF SECTIONS OF ANY CLASS OF HEAT RESISTANCE
06
simplicity, speed, and quality installation
DELIVERY FROM 14 DAYS WORLDWIDE
RBC IN NUMBERS
Our history
100
25
200 000
coils per year
pieces of technical equipment for coils manufacturing
graduated employees
500
> 3000
40
countries around the world use our products
pcs. base of electric motors
customers have been ordered from us at least once
SIMPLE AND CONVENIENT ORDERING
CONTACTS US
Tell us about you technical problem at hand and let us become your partner.
Submit your request and we’ll find a solution for you.
